Okenseiko 精 O O O P08K04P Жидкий насос/точный инструмент
Вес товара: ~0.7 кг. Указан усредненный вес, который может отличаться от фактического. Не включен в цену, оплачивается при получении.
Описание товара
Джи Ян Джинггонг
Жидкий насос жидкого насоса
P08K04R
совершенно новый
SPEC SHEET
Имя: Жидкий насос (жидкий насос)
Model:P08K-0004R
Rated Voltage: 12VDC
Operating Voltage Range:   9,0 ～ 13,5VDC
Operating Temperature Range:   0 ～ 50,0 ℃
Storage Temperature Range: -20 ~ 60 ℃
Fluid to use: Water (20&Plusmn; 5 ℃)
Основной поток производительности ※ 1 0.15 L/min(Min)
Current Draw 130 mA(Max)
Dead Head Pressure 120 kPa(Max)
Noise Level ※ 2 58 dB(Max)
Cautions:
1. Wrap with a piece of soft polyurethane and fix it inside the device used.
2. If metal binder is used, bind around the motor.
3. Most preferably horizontal. If vertical, motor side down.
4. This pump is designed for positive pressure not for negative pressure.Pressure of inlet port
must be over-5kPa.It must be careful for clogs of nozzle and strainer.
5. Solvent may damage plastic parts. Oil and fat, some types of chemicals of plasticizer possible
contained in rubber of silicone tubes may also damage plastic parts.
6
7. It must be done some measures against water leak including motor point of contact,as it might
happen some unexpected accidents such as water leak due to diaphragm burst.
8. Please do not use the product(rubber, seal medicine, oil, and adhesive, etc.)that contains
silicon or sulfur in the same atmosphere as the pump, It becomes an insulation material by
generating a low molecular silicon gas and su1furetted gas, As a result, Please use it by the
responsibility after it is confirmed that there is no problem using it enough if the product
including silicon or sulfur is used.
Remarks
※ 1 Conditions of sucking range 20 cm.
Discharge 0 cm
※ 2 At 30cm distance when measured in A range.
