SM42HT33-0316ASM42HT33-1334ASM42HT38-1206ASM42HT38-0806A
Вес товара: ~0.7 кг. Указан усредненный вес, который может отличаться от фактического. Не включен в цену, оплачивается при получении.
Описание товара
Model No. | Rated Voltage | Current | Resistance | Inductance | Holding | #Of Leads | Rotor Inertia | Weight | Length | ||
Single Shaft | Double Shaft | V | A | Ω | mH | Oz-in | g-cm | | g-cm2 | Kg | mm |
SM42HT33-0956A | SM42HT33-0956B | 4 | 0.95 | 4.2 | 2.5 | 22 | 1580 | 6 | 35 | 0.22 | 33 |
SM42HT33-0406A | SM42HT33-0406B | 9.6 | 0.4 | 24 | 15 | ||||||
SM42HT33-0316A | SM42HT33-0316B | 12 | 0.31 | 38.5 | 21 | ||||||
SM42HT33-1334A | SM42HT33-1334B | 2.8 | 1.33 | 2.1 | 2.5 | 30 | 2200 | 4 | |||
SM42HT38-1206A | SM42HT38-1206B | 4 | 1.2 | 3.3 | 3.2 | 36 | 2590 | 6 | 54 | 0.28 | 38 |
SM42HT38-0806A | SM42HT38-0806B | 6 | 0.8 | 7.5 | 6.7 | ||||||
SM42HT38-0406A | SM42HT38-0406B | 12 | 0.4 | 30 | 30 | ||||||
SM42HT38-1684A | SM42HT38-1684B | 2.8 | 1.68 | 1.65 | 3.2 | 50 | 3600 | 4 | |||
SM42HT47-1206A | SM42HT47-1206B | 4 | 1.2 | 3.3 | 2.8 | 44 | 3170 | 6 | 68 | 0.35 | 47 |
SM42HT47-0806A | SM42HT47-0806B | 6 | 0.8 | 7.5 | 6.3 | ||||||
SM42HT47-0406A | SM42HT47-0406B | 12 | 0.4 | 30 | 25 | ||||||
SM42HT47-1684A | SM42HT47-1684B | 2.8 | 1.68 | 1.65 | 2.8 | >70 | >5000 | 4 | |||
